Product Description

4.5", Automatic,Enclosed Optical Engine

Projection Specification

Projection Parameter

Digital LCD and Enclosed Optical Engine

Display Source

LED Light Source

Light Life

> 15000 Hours

Light Luminance

500ANSI

Standard Resolution

1920*1080P

Projection Area

29-200inch

Contrast Ratio

1500:1

Projection Ratio

1.15:1

Distortion Ratio

<1.0%

Luminance Uniformity

>63%

Projection Distance

0.9M-4.5M

Aspect Ratio

Default is 16:9, 4:3 also is optional

Focus mode

Auto-Focusing

Special Function

Auto-Focusing
Auto-Keystone
Auto-Entry
Auto-Obstacle Avoidance

Keystone Correction

Automatical

Projector Character

Interactive

Projection Mode

Desktop Projection
Rear Projection-Desktop
Front Projection-Desktop

LED Luminous efficiency

~90%;10000LUX

System Specification

Screen  Mirror

Support

OS

Android 9.0

CPU

MTK9269@ARM Cotex A73*4(Quad Core)

GPU

Mali-G52

Buffer Memory

1GB DDR4+1G Intelligent Storage

Memory

32GB eMMC

WIFI

Dual Band WiFi6(2.4G/5.8G)

Bluetooth

BT5.1

4G Mobile Data

4G Cat4 Mobile Data is Optional

Basic Specification

Video Format(up to 4k)

                                               Video Codec：HEVC/H.265、MPEG1/2、MPEG4、H.263、H.264、VC1                                                                  Container：stream(.ts, .trp, .tp)
MKV(.mkv)
MPEG program stream(.DAT, .VOB, .MPG, .MPEG)
MPEG transport stream(.ts, .trp, .tp)
MP4(.mp4, .mov)
MKV(.mkv)
3GPP(.3gpp, .3gp)
AVI(.avi)
MPEG transport
stream(.ts, .trp, .tp)
ASF(.asf)
WMV(.wmv)
AVI(.avi)
MKV(.mkv)
  stream(.ts, .trp, .tp)

                                                                                                                       FLV(.flv)

Audio Support

MPEG(MP3),PCM,ADPCM(wav),MPEG(mka) etc.

Image Support

JPEG、PNG、BMP、gif

Voice Remote Control

Voice Remote Control

Built-in Speaker

4Ω@8Wx2,HiFi Sound Quality.
(Digital DSP Chipset on PC Main PC Board Supported)

Light machine  Consumption

75W

Whole Power Consumption

< 100W

Power Performance

AC 100~240 / 50~60HZ

Interface

HDMI2.0*1

USB2.0*1

AV/Ω*1(Both AV and Headset are Compatible)

RJ45*1 With 10M/100M Data Rate

S/PDIF*1 With Fiber Optic Digital Audio

Package and Color

Colour

Metallic Grey,Silver,Royalblue; Default Color is Royalblue.

Dimension

260mm*260mm*105mm

Net weight

2.425Kg

Gift Box weight

3.35Kg

Gift Box Size

155mm*155mm*315mm(Length*Width*High)

Carton  Box size

Four to a Carton Box, its size is 675mm*362mm*352mm

Standard Accessories

Voice Remote Control,User Manual,Power Cord,Foot Screw.

Gross Weight Per Carton

13.65Kg
